One technique that is particularly useful is to use one layer within the board as a ground plane. The only satisfactory solution is to use a ground plane which provides a low inductance and low resistance common ground which can provides a method of providing a short lead length to ground. Major instructional emphasis is placed on real-life examples that demonstrate optimal layout practices that can be incorporated immediately.
